Hollingsworth Enterprises, Inc.

Note:
Convert Metric Threads to 1/8" NPT
Adds 1" to Bayonet Adaptor Length

PART NUMBER - METRIC THREAD

HMEA - A-1 - 10 x 1.5 mm
HMEA - B-1 - 12 x 1 mm
HMEA - C-1 - 12 x 1.5 mm
HMEA - D-1 - 14 x 1.5 mm
HMEA - E-1 - 14 x 2 mm

Note:
Lock Cap, S/S Spring, and 2 Braze Rings

PART NUMBER

H430

PART NUMBERS

H439 1/8" Adjustable Fitting w/ Brass Ferrule

H439-NY 1/8" Adjustable Fitting w/ Nylon Ferrule

H439-SS 1/8" Adjustable Fitting w/ Stainless Ferrule

H439-3mm 3mm Adjustable Fitting w/Brass Ferrule

H439-3mm-S 3mm Adjustable Fitting w/ S/S Ferrule

H439-M Same as H439 except w/ Metric Lock Cap

PART NUMBERS

H432 S/S Spring, 3/16" Probe, 1 5/8" long
H432-1 S/S Spring, 1/8" Probe, 1 5/8" long
H432-2 S/S Spring, 3/16" Probe, 2" long
H432-4 S/S Spring, 1/4" Probe, 2" long
H432-96 S/S Spring, 3/16" Probe, 96" long
H433 "17-7PH" Spring, 3/16" probe, 1 5/8" long
H433-1 "17-7PH" Spring, 1/8" Probe, 1 5/8" long
H435 12" long S/S Spring Only
H435-P 8" long S/S Spring Only, Bell Shaped End

PART NUMBERS

H434 Bayonet Lock Cap Only, 3/16" Probe
H434-SS S/S Bayonet Lock Cap Only, 3/16" Probe
H434-M Metric (Double Slot) Lock Cap, 3/16" Probe
H434-1 Bayonet Lock Cap Only, 1/8" Probe
H436 Bayonet Lock Cap to run on H601 armor
H436-SS S/S Bayonet Lock Cap to run on H601 armor
H436-M Metric (Double Slot) Lock Cap for H601 armor
H436-1 Bayonet Lock Cap to run on H600 armor
H436-5/32 Bayonet Lock Cap to run on H60-5/32 armor
H436-M-1 Metric (Double Slot) Lock Cap for H600 armor
H437 Bayonet Lock Cap to run on H435 Spring
H437-SS S/S Bayonet Lock Cap to run on H435 Spring
H437-M Metric (Double Slot) Lock Cap for H435 spring

PART NUMBERS

H438 Braze Ring (S/S) for 3/16" Probe (Bags of 200)
H438-1 Braze Ring (S/S) for 1/8" Probe (Bags of 200)
H438-4 Braze Ring (S/S) for 1/4" Probe
